Guardian 4s16

$239.00$529.00

Level IV Stand Alone

SKU: 4s16

Request Quote
Register to Buy Online
Categories: ,

The Guardian 4s16™ Level IV Stand Alone ceramic plate provides rifle armor protection from armor-piercing rounds. Made in the USA, the 4s16 has been independently tested by an NVLAP accredited laboratory according to NIJ Standard 0101.06 level IV ballistic threats.

  • Protection: Level IV Stand Alone Armor Piercing
  • NIJ Standard 0101.06 TESTED: This product has been independently tested by an NVLAP accredited NIJ approved laboratory to meet or exceed ballistic resistance as specified under NIJ Standard 0101.06
  • RST: Rifle Special Threats Validated
  • Material: Ceramic + UHMWPE
  • Exterior Cover: 1000D CORDURA®, Textured Nylon
  • Thinness: 0.75”
  •  Cut: Available in Shooters, Swimmers, SAPI, and Full (10” x 12” shooters cut is considered nominal 9.5” x 11.5” dimensions)
  • Warranty: 5 years on all ballistic material excluding exterior cover and 1 year on exterior cover material and workmanship
Size Curvature Cut Weight
5 x 7Single CurveFull2.31 lbs / 1.05 kg
5 x 8Single CurveFull2.65 lbs / 1.20 kg
6 x 6Single CurveFull2.20lbs / 1.00 kg
6 x 8Single CurveFull3.09 lbs / 1.40 kg
8 x 10Single CurveFull5.14 lbs / 2.33 kg
8 x 10Single CurveShooters5.00 lbs / 2.27 kg
10 x 12Single CurveFull7.64 lbs / 3.47 kg
10 x 12Single CurveShooters6.46 lbs / 2.93 kg
10 x 12Single CurveSwimmers6.61 lbs / 3.00 kg
10 x 12Muti CurveShooters6.46 lbs / 2.93 kg
7¼ x 11½Muti CurveSAPI (XS)4.91 lbs / 2.23 kg
8¾ x 11¾ Muti CurveSAPI (S)6.31 lbs / 2.86 kg
9½ x 12½Muti CurveSAPI (M)7.31 lbs / 3.32 kg
10 x 13¼Muti CurveSAPI (L)8.38 lbs / 3.80 kg
11 x 14Muti CurveSAPI (XL)9.24 lbs / 4.19 kg
StandardWeaponProjectileGRVEL FT/SVEL M/S(+/- ft/s)
NIJ 0101.06Rifle.30 Caliber Armor Piercing (AP) Bullets (M2 AP)1662880878(+/- 30)

Guardian 4s16 Product Spec
