Guardian 4sss2

$949.00$2,060.00

Level IV Stand Alone

SKU: 4sss2

Request Quote
Register to Buy Online
Categories: ,

The Guardian 4sss2™ is an Ultra-lightweight rifle armor insert and provides multi-hit rifle armor protection from armor-piercing rounds. Made in the USA and constructed from lightweight silicon carbide, the 4sss2 is NIJ 0101.04 (2005IR) compliant/certified.

  • Protection: Level IV Stand Alone Armor Piercing
  • NIJ Standard 0101.04 (2005 IR) CERTIFIED: This product is NIJ 0101.04 (2005 IR) compliant “Certified” by NIJ.
  • RST: Rifle Special Threats Validated
  • Thinness: 0.97”
  • Exterior Cover: 1000D CORDURA®, Textured Nylon
  • Material: Lightweight Silicon Carbide Based Hard Armor Plate with UHMWPE
  • Cut: Available in Shooters, Swimmers, SAPI, and Full (10”x12” shooters cut is considered nominal 9.5”x11.5” dimensions)
  • Warranty: 5 years on all ballistic material excluding exterior cover and 1 year on exterior cover material and workmanship
Size Curvature Cut Weight
7¼ x 11½Muti CurveSAPI (XS)3.9 lbs
8¾ x 11¾ Muti CurveSAPI (S)5.05 lbs
9½ x 12½Muti CurveSAPI (M)5.74 lbs
10 x 13¼Muti CurveSAPI (L)7.2 lbs
11 x 14Muti CurveSAPI (XL)7.5 lbs
StandardWeaponProjectileGRVEL FT/SVEL M/S(+/- ft/s)
NIJ 2005 IRRifle.30 Caliber Armor Piercing (AP) Bullets (M2 AP)1662880878(+/- 30)
DEA 2017Rifle.223 Remington Tactical Bonded Soft Point622600792(+/- 50)
DEA 2017Rifle5.56 x 45mm M855 (Green Tip)623100945(+/- 50)
DEA 2017Rifle7.62 x 39mm Mild Steel Core1232400731(+/- 50)
DEA 2017Rifle7.62 mm FMJ, Steel Jacketed Bullets (M80)1472750838(+/- 50)
DEA 2017Rifle.308 Winchester PSPB Core-Lokt Ultra Bonded1502600792(+/- 50)
SpecialRifle.223 SCS Brush Hog553150960(+/- 50)
SpecialRifle5.56 x 45mm M193 FMJ553250991(+/- 50)
SpecialRifle7.62 x 39mm (BZ API)1222380725(+/- 50)
SpecialRifle7.62 x 51mm (M61 AP)150.52750838(+/- 50)
SpecialRifle7.62 x 54R (LPS)1482880878(+/- 50)
SpecialRifle7.62 x 54R-b-32 API1552800853(+/- 50)
SpecialRifle7.62 x 63mm-JSP1502780847(+/- 50)
SpecialRifleRifle AK-47, M, SKS 7.62 x 39mm Ball1232380725(+/- 50)
HighCom Armor Guardian 4sss2 Hard Armor Plate Product Spec PDF page

Guardian 4sss2 Product Spec

External file Download

Image of HighCom Armor Guardian Plates Overview PDF catalog with hard armor plate and company logo

Guardian Hard Armor Plates Overview

External file Download

HighCom Armor Guardian Hard Armor Threat Chart Cover Page PDF

Guardian Hard Armor Threat Chart

External file Download
